- Page 1 INSTRUCTION MANUAL AIR 24 www.aivituvin.com...
- Page 3 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 4: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x35mm SCREW M3.5x45mm SCREW 4PCS+1spare 12PCS+1spare M3.0x16mm SCREW M3.5x20mm SCREW 2PCS+1spare 8PCS+1spare Chewing toy M3.0x10mm SCREW 2PCS+1spare Lock M3.0x16mm SCREW 4PCS+1spare... - Page 5 PARTS Side panel of wooden Back panel Front panel hutch Middle panel of wooden Side panel of pen Floor of wooden hutch hutch Roof of pen Wire floor Plastic tray...
- Page 6 PARTS Casters without brakes Brake casters Wooden roof 2PCS 2PCS 2PCS Roof cap Folding metal feeder Wire floor supporter...
- Page 7 PARTS Hutch...
-
Page 8: Product Assembly
PRODUCT ASSEMBLY ① Attach the side panel Part E & Part C to the front panel Part A by 2xP1 each. ② Attach the middle panel Part D to the front panel Part A by 2xP2. ① Attach the back panel Part B by 2xP1 at each side and 2xP2 at the middle. - Page 9 PRODUCT ASSEMBLY ① Put the wooden floor Part F into the wooden hutch. ② Put the wire floor Part H into the pen. ③ Slide in the plastic tray Part I. Attach the pen roof Part G by 4xP1. ① Screw the lock P7 to the side of pen by 4xP8.
- Page 10 PRODUCT ASSEMBLY Attach the wodden roof Part J by 2xP4 each.
- Page 11 PRODUCT ASSEMBLY Screw in the casters Part L & K to the legs. ① ② Screw the roof cap Part M by 2xP3. LOCKED OPEN Finish...
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
