- Page 1 INSTRUCTION MANUAL AIR20-B www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWERE M3.5x35mm SCREW M3.5x45mm SCREW 8PCS+ +1spare 12PCS spare M3.0x10mm SCREW M3.0x16mm SCREW 2PCS ++ 1 spare 18PCS ++ 1 spare Latch Eye hook 2PCS+ Chewing Toy for Gift... - Page 4 PARTS Left Panel Front Panel Back Panel 1 PC 1 PC 1 PC Right Panel Top Cover Panel Sliding Tray 1 PC 1 PC 1 PC Ramp Layer Divider 1 PC 1 PC 1 PC...
- Page 5 PARTS Brake Casters Wood Floor Casters without brake 1 PC 2 PCS 2 PCS Bootom Wire Netting Extra Hutch Legs Folding Metal feeder (Optional) 1 PC 1 PCS 4 PCs Wood shelf 1 PC...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY OPTIONAL- HUTCH ON THE GROUND Follow the step from step 1 to step 10 to finish! OPTIONAL- HUTCH WITH 4 HIGH LEGS. Follow the step from step 1 to step 8,skip the Step9 & Step 10,then go on until the last step to finish! - Page 7 PRODUCT ASSEMBLY Attach Part A, Part C and Part D by 4xP1 screws. And then attach divider Part I to Part A by 2xP1 screws. Attach back panel Part B by 4xp1 screws.And Screw another side of divider to the back by 2xP1 screws.
- Page 8 PRODUCT ASSEMBLY Slide in the tray Part E. ① Put inside the bottom wire netting PART M to be UPWARDS, to seperate the urine & poop. ② Put inside the wood floor Part J as show on the picture. ③ ...
- Page 9 PRODUCT ASSEMBLY ① Screw the ramp Part G to the upper frame of divider Part I by 4xP3. Put the layer Part H above the divider,it can be removable freely to ② catch the pets. ③ Put the chewing toy P7 inside the cage anywhere you want. Attach the top cover panel Part F to the house by 6xP3 screws.
- Page 10 PRODUCT ASSEMBLY ① Screw the folding metal feeder Part O to the inside of Part D by 2xP4 screws. ② Screw the eye hook P5 to the Part C, tie the rope on one side of roof ,the other side of hook to make the roof open. Screw latch P6 to the Part C by 4XP3 screws as show on picture.
- Page 11 PRODUCT ASSEMBLY Below steps are optional: If you want to put the the hutch on the ground, followthe Step 9,Step 10 to finish ! If you want to make the hutch with 4 higher legs, just skip Step 9 ,Step 10 and go on Step 11 to Step 14 to finish.
- Page 12 PRODUCT ASSEMBLY Screw two casters without brake Part L to the front of hutch legs. Attach the extra high legs Part N to the front by 2xP2 screws each side.
- Page 13 PRODUCT ASSEMBLY Attach the extra high legs Part N to the back by 2xP2 screws each side. Screw two brake casters Part K to the back of hutch legs.
- Page 14 PRODUCT ASSEMBLY Screw two casters without brake Part L to the front of hutch legs.
- Page 16 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
