- Page 1 INSTRUCTION MANUAL AIR 29...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
- Page 3 Notice Read Before Assemble! ① The below steps are using for chicken coop AIR27 and enclosure AIR29 combination,pls ignore if you don't have chicken coop AIR27. ② There are 3 different combination for your optional choice. Option 1 Pls refer to page 9. Option 2 Pls refer to page 10.
- Page 4 Notice Read Before Assemble! ① The below steps are using for the chicken coop and enclosure combination pls ignore if you don't have chicken coop. ② AIR29 can attach to coop AIR27,AIR31,AIR32,AIR61. AIR29+AIR31: Pls refer to page 12 . AIR29+AIR32: Pls refer to page 13.
- Page 5 Notice Read Before Assemble! AIR29+AIR61: Pls refer to page 14 .
-
Page 6: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M6.0x25mm BOLT M6.0x30mm BOLT 4PCS+1spare 16PCS+1spare M6.0x20mm BOLT Lock 4PCS+1spare 2PCS Screw driver Ties 2PCS + 2PCS SPARE M3.5x45mm SCREW 8PCS+1spare... - Page 7 PARTS Right side of front panel Part A opposite side Left side of the front panel Part B opposite side Left panel Right panel Roof Perch 2PCS...
-
Page 8: Product Assembly
PRODUCT ASSEMBLY Attach Part A, B, C, D to E, F by bolt 12xP1. X 12 Insert the perch Part H into slots inside front and back panel.. - Page 9 PRODUCT ASSEMBLY Attach the roof Part G by 4xP1 as show on the picture. Attach the lock P4 by 2XP3 each side. Finish here for using the enclosure alone !
- Page 10 Notice Read Before Assemble! The below steps are using for chicken coop AIR27 and enclosure AIR29 combination,pls ignore if you don't have chicken coop AIR27. OPTION 1 ① Take out the casters of coop. Take out the right side pen panel of coop. ② ...
- Page 11 OPTION 2 ① Take out the casters of coop. Take out the right side pen panel of coop. ② Push upward the hinge to take out the front door of enclosure. ③ Push upward to take out Attach the enclosure to the coop by 2XP5 ties and 2XP7 screws.
- Page 12 OPTION 3 Take out the casters of coop. ① Take out the spring latch of the pen of coop. ② Push upward the hinge to take out the door of the front pen of coop. ③ Take out the small door of left panel of enclosure. ④ ...
- Page 13 Notice Read Before Assemble! The below steps are using for chicken coop AIR31 and enclosure AIR29 combination,pls ignore if you don't have chicken coop AIR31. Push upward to take out the small door of right panel of coop. ① Take out the small door of left panel of enclosure. ②...
- Page 14 Notice Read Before Assemble! The below steps are using for chicken coop AIR32 and enclosure AIR29 combination,pls ignore if you don't have chicken coop AIR32. Take out the right side panel of coop. ① Take out the small door of left panel of enclosure. ②...
- Page 15 Notice Notice Read Before Assemble! Read Before Assemble! The below steps are using for chicken coop AIR61 and enclosure AIR29 combination,pls ignore if you don't have chicken coop AIR61. ① Take out the small door and push handle of coop. ② Take out the small door of left panel of enclosure. Attach the enclosure to the coop by 2XP7 screws and 2XP5 ties.
- Page 16 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
