Summary of Contents for aivituvin AIR 25
- Page 1 INSTRUCTION MANUAL AIR 25 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.0x30mm SCREW M3.5x40mm SCREW 4PCS+1spare 26PCS+1 spare M3.0x12mm SCREW Eye hook 4PCS+1 spare Bowl Chewing Toy for Gift... - Page 4 PARTS Right panel Left panel Front panel Back panel Platform Platform Platform Platform Platform...
- Page 5 PARTS Ramp Sliding tray Layer Top cover panel Platform...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Attach Part B Part C and Part D by 4xP2 screws. Put the platform Part E, F, G, H, I, N in the show position and ready for the next step's assemble. - Page 7 PRODUCT ASSEMBLY ① Screw the platform Part E ,F ,G ,H, I, N one by one to the inside of back panel Part D by 12xP2 screws as show on the picture. ② Screw the platform Part F from right panel by 2xP2 screws. ① Screw the platform Part G &...
- Page 8 PRODUCT ASSEMBLY ① Attach front panel A by 4xP1 screws. ② Slide in the tray Part L. ① Attach the top cover panel Part M to the house by 4xP3 screws. ② Notice to level up with the hinges.
- Page 9 PRODUCT ASSEMBLY ① Screw the eye hook P4 to the left panel Part B, tie the rope on one side of roof, the other side of hook to make the roof open. ② Put the bowl Part P6 and chewing toy Part P5 inside the cage in anywhere you want.
- Page 10 PRODUCT ASSEMBLY Attach the Part J to bottom shelf of Part B and Part C by 4xP2 screws.
-
Page 11: Help Center
Once the items are received, opened, and deemed to be faulty or other problems. Pls contact us at service@aivituvin.com for the solution. We will feedback to you within 24 hours. If you are happy with the shopping ,welcome to share photos and thoughts with others . - Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
