Communication Ports
4.2 Copper Ethernet Ports
Specifications
For specifications on the available copper Ethernet ports, refer to "Copper Ethernet
Port Specifications" (Page 32).
30
Pin
10/100Base-TX
8
Reserved (Do Not Connect)
Name
1000Base-TX
BI_DC-
Description
Bi-Directional
RUGGEDCOM RSG909R
Installation Manual, 04/2023, C79000-G8976-1388-17
