Valor LX2 Series Installation Manual

INSTALLATION MANUAL
Lighting Rail Overlay
Use ONLY with Valor heater models LX2 Series
This overlay is intended to cover the top light rail on
Valor LX2 fi replace models.
Installation
To secure the overlay:
1. Remove front screen and front window. See
fi replace installation manual for procedure.
2. Release 4 screws from top light rail.
Do not remove screws!
3. Insert overlay covering the light rail metal part. You
may need to push quite hard.
4. Tighten the 4 screws released in step 2.
Light rail
Overlay
Overlay installed
Because our policy is one of constant development and improvement, details may vary slightly from those given in this publication.
Designed and Manufactured by / for Miles Industries Ltd.
190 – 2255 Dollarton Highway, North Vancouver, B.C., CANADA V7H 3B1
Tel. 604-984-3496 Fax 604-984-0246
www.valorfi replaces.com
LX2 Series
© Copyright, Miles Industries Ltd., 2018
Light rail Overlay—Part no. 4007370AH
Front view
Rear view
