Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
CAN Junction
(green CAN junction connector
behind glove box)
10 24 38
9 23 37
8 22
36
7 21 35
6 20 34
5 19 33
18 32
31
4 17
16 30
15 29
3
BCM
14 28
2 13 27
12 26
11 25
1
BCM
(black connector, plug - E,
above passenger kick panel)
D2D Port
(+) Ignition Input / Output
(-) Hood Pin Input
(AC) Tach Input
(-) Ground
(-) Ground
(+) 12V Input
BCM
(black-gray conn. above
passenger kick panel)
1 2
3 4
(+) 12V:
Violet/Red, pin 3
7 403.CHRYSLER22 1.09 2022 Dodge/Ram Charger (Smart Key)
©2023 Directed. All rights reserved.
CAN C High:
White/Green, pin 1
CAN C Low:
White/Blue,
pin 2
48
47
46
45
44
43
(+) Ignition Sense:
42 Pink/White, pin 27
41
40
39
Immobilizer Data:
White/Lt. Green, pin 5
CUT
1
2
3
CAN Junction
(white CAN junction connector
under driver dash)
Immo. Data Interr. (veh. side): Yellow: 8
Immo. Data Interr. (conn. side): Orange/Yellow: 9
(MUX) Parking Light Output: Violet/Brown: 9
(+) PTS: Violet/Lt. Blue, pin 4
Keyless
Ignition Node
(black conn. at
Start-Stop button)
CAN IHS High:
White/Gray
or White Green,
CAN IHS Low:
White/Orange
or White,
HS CAN 2 High: Tan/Black: 3
HS CAN 2 Low: Tan: 4
HS CAN 1 High: Orange/Green: 5
HS CAN 1 Low: Orange/Brown: 6
(AC) Tach Output: Violet/White: 5
(+) PTS Output: Gray/Black: 7
Headlight Switch
(black connector)
3
6 5 4 2 1
(MUX)
Parking Lights:
White/Brown, pin 3
).
pin 1
1
XKD2D65
2
3
pin 2
