Installation; Wiring Diagram With T-Harness (Thchd3 Rev.3+) - Directed DB3 Installation Manual

Wiring diagram with T-Harness (THCHD3 Rev. 3+)
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
CAN Junction
(green CAN junction connector
behind glove box)
10 24 38 48
9 23 37 47
8 22
36 46
7 21 35 45
6 20 34 44
5
19 33 43
18 32 (+) Ignition Sense:
31
4 17 42
Pink/White, pin 27
16 30
15 29
3 41
BCM
14 28
2 13 27 40
12 26
11 25
1 39
BCM
(black connector, plug - E,
above passenger kick panel)
(-) Hood Pin Input
(+) Ignition Input / Output
(AC) Tach Input
(+) 12V Input
(-) Ground
1 2
D2D Port
3 4
1
(+) 12V:
Violet/Red, pin 3
6 403.CHRYSLER22 1.09 2022 Dodge/Ram Charger (Smart Key)
©2023 Directed. All rights reserved.
male
Connect T-Harness
Keyless Ignition Node
male connector
into PTS switch (black connector
at PTS switch)
Female
Male
T-01
(6-pin black connector)
CAN C High:
White/Green, pin 1
1
2
CAN C Low:
3
White/Blue,
pin 2
CAN Junction
(white CAN junction connector
under driver dash)
Hood Pin
BCM
(black-gray conn.
passenger kick panel)
Connections required for Rev. 3 ONLY
Not Used
Not Used
Female
Male
T-02
(6-pin white connector)
4 CAN Loops.
HS CAN 1 High: Orange/Green
HS CAN 1 Low: Orange/Brown
HS CAN 2 Low: Tan
HS CAN 2 High: Tan/Black
CAN IHS High:
White/Gray
or White Green,
pin 1
CAN IHS Low:
White/Orange
or White,
pin 2
(AC) Tach Output: Violet/White
(MUX) Parking Light Output: Violet/Brown
Headlight Switch
(black connector)
3
6 5 4
(MUX)
Parking Lights:
White/Brown, pin 3
Diagnostic Connector
The Remote Start Safety
Override Switch is inactive
(used for RSR only)
THCHD3
Rev. 3+
Cut ALL
(optional T-Harness)
Use the style of OBDll
connector that fits the best.
1
2
3
2 1
).
D2D
only
OBDII
male
female
OR
Do not connect
