16-pin 2.54 mm JTAG Adapter

This adapter must be ordered separately to connect to the target featuring 16-pin 2.54 mm pitch
JTAG target debug connector. The adapter is used only in conjunction with iSYSTEM solutions
supporting Infineon AGBT trace interface (e.g. Infineon AGBT Active Probe ).
The following pinout is valid on the target side:
Signal
Signal Direction
Description
JTAG / DAP
O / IO
Data pin
I JTAG
Not Connected
O JTAG
O JTAG
JTAG / DAP
O / O
Clock
Not Connected
Not Connected
Signal Direction is described from the BlueBox perspective.
Ordering code
Signal Pin
TMS/DAP1 1
TDO 3
NC 5
TDI 7
nTRST 9
TCK/DAP0 11
NC 13
NC 15
16-pin 2.54 mm TriCore JTAG pinout
IASAM22TRICOREPIN16
Pin Signal
2 Vref
4 GND
6 GND
8 nPORESET
10 NC
12 GND
14 NC
16 NC
Signal
Signal Direction
Description
Reference
I
Voltage
Ground
Ground
Power On
IO
Reset
Not Connected
Ground
Not Connected
Not Connected
