Wiring Diagram - Directed DB3 Installation Manual

Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
(+) Starter:
Yellow/Black, pin 23
D2D Port
(+) Starter Output
(+) Ignition Input/Output
(+) Accessory Output
(-) Hood Pin Input
(-) Ground (-) Ground
(AC) Tach Input
(+) 12V Input
(+) 12V:
Green, pin 1
1
Fuse Box
(white conn.
at drivers kick)
6 403.MA3 2.41 2022 Mazda MX-5 Miata (Smart Key)
©2023 Directed. All rights reserved.
or
HS CAN Low: Green/Red Blue, pin 8
or
HS CAN High: Pink Green, pin 7
Start/Stop Unit
(white conn. at
steering column)
10 9 7 6 5 4 3 2
12 11 8 1
24 23 22 21 20 19 18 17 16 15 14 13
(+) Ignition:
(+) Accessory 2:
or
Lt. Blue Brown, pin 10
or
Gray
Hood Pin
Pink, pin 20
Keyless Data:
Blue, pin 9
16 15 14 13 12 11 10 9 8 7
32 31 30 29 28 27 26 25 24 23 22 21
Start/Stop Unit
Red/Black
(white conn. at
steering column)
(-) Parking Lights:
Blue, pin 1
1 2 3 4 5 6
Parking Lights:
Refer to "Accessing the parking
Black, pin 2
light circuit" section for more
Cut information.
Parking Lights Interr. (conn. side): Yellow: 8
Tan, pin 14
Parking Lights Interr. (veh. side): Orange/Yellow: 9
(+) Ignition Interr. (conn. side): Orange/Red: 10
(+) Ignition Interr. (veh. side): Yellow/Red: 11
(-) Push-to-Start Output: Green/Black: 2
(-) PTS:
(AC) Tach Output: Violet/White: 5
Keyless Data Output: Orange/Black: 11
(-) Parking Lights Output: Blue/Red: 12
6 5 4 3 2 1
20 19 18 17
Ignition 2 Interr.:
or
Violet
or
Tan, pin 17
Cut
Parking Light
7 8
Switch Assembly
HS CAN High: Tan/Black: 3
HS CAN Low: Tan: 4
).
XKD2D65
