Latte Functional Overview - Texas Instruments DS560DF410EVM User Manual

Software Description
Continue the installation setup to complete FTDI Driver installation
2. Install the Latte Libraries updater. Follow all the instructions within the installer execution process. The
installer will install the Latte device library required for configuring DS560DF410EVM
Select project directory as "C:\Users\<User ID>\Documents\Texas Instruments\DS560Latte".
Replace the <User ID> with the proper Windows login ID.
TI may update both the base Latte software and the DS560 Latte Library to add features and
optimizations.

2.2 Latte Functional Overview

The user can launch the DS560Latte GUI through the desktop shortcut icon or select App – DS560Latte.
2-4 shows the Latte GUI main window. The Latte user interface is split into eight windows (labeled 1 to 8 on
Figure 2-4) with the following functionality:
Window 1:
This window (also called Scripts) shows the list of python scripts available that generate the register
commands to configure the DS560EVM. The script files shown are located in the ..\Documents\Texas
Instruments\DS560Latte\projects\DS560\ folder. You can modify and create new scripts as necessary,
which appear in this sub-window when you restart Latte.
Window 2:
This window (also called Editor) shows the code in the script currently selected and can be used to modify and
save the code as necessary.
Window 3 to 6:
These windows get updated with status information as the user runs the scripts to configure the DS560DF410.
Window 7:
This window (also called Command Line) is used to enter and run individual commands. Examples of such
commands include changing the TX swing, pre or post emphasis settings, configuring PRBS generator or
checker and so on.
Window 8:
This window (also called Log) displays messages during execution of scripts to display the current status. This
window is also used for troubleshooting.
