Rotabroach ELEMENT 50 AUTO Manual page 21

Element 50 AUTO Manual
PARTS LIST
Item#
8.1
8.2
8.3
8.4
8.5
8.6
8.7
8.8
8.9
8.10
8.11
8.12
8.13
8.14
8.15
8.16
8.17
8.18
8.19
8.20
8.21
8.22
8.23
8.24
8.25
8.26
8.27
8.28
8.29
8.30
8.31
8.32
8.33
8.34
8.35
8.36
8.37
8.38
8.39
8.40
Original Instructions
Rotabroach P/N Description
RDC4007 Circlip
RDC4008 Oil Seal Washer
RDC4009 Arbor Spindle
RDC4010 Roll Bearing
RDC4011 Flat Key
RDC4012 Tapping Screw
RDB4008 Spring
RDB3030 Gear Lever
RDC4013 Screw
RDC4014 Gear Box
RDC4015 Needle Bearing
RDB4004 Gear Shaft Washer 10mm ID
RDB3048 Key Steel
RDB3046 Gear Axel
RDB2010 Gear Lever Shaft
RDB2022 Dual Gear
RDB4002 Washer
RDC4016 Needle Bearing
RDC4017 Circlip
RDC4018 Big Gear
RDC4019 Roll Bearing
RDC4020 Oil Seal
RD45614 Straight Pin
RM17134 Rolling Bearing 608
RDC4021 Shaft Gear
RDC4022 Flat Key
RDC4023 Gear
RDC4024 Oil Baffle Plate
RDC4025 Inner Gear Plate
RDC4026 Seal Washer
RD45522 Rolling Bearing 6001
RDC4027(230V) Armature(230V)
RDC4028(110V) Armature(110V)
RD43603 Rolling Bearing 629
RDB3069 Bearing Sleeve
RDC4029 Inductor
RDC4030 Baffle Plate
RDC4031 Tapping Screw
RDC4032(230V) Field Coil(230V)
RDC4033(110V) Field Coil(110V)
RDC4034 Lead Wire
RDC4035 Lead Wire
21
June 2022
Qty/pcs
1
1
1
1
1
4
1
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
