STEP 1
Read the Safety Instructions
• It is very important to read the safety instructions on pages 4 and 5.
IMPORTANT: It is the installer's responsibility to comply with installation clearances.
STEP 2
Unpack Range Hood and Prepare Tools
• Carefully unpack the range hood and parts. Make sure all parts are included as shown on page 6.
• DO NOT remove the protective film covering the appliance until the installation is fully completed.
• Consult a qualified and trained installer or check local codes for makeup air requirement, if any.
STEP 3
Plan Desired Location
• Designed for ceiling heights between 7.6 ft. to 9.5 ft. (2.3 - 2.9 m) only. Refer to Height and Clearance section.
• Plan a desirable location that fits all requirements in the Safety and Installation sections of this manual. Plan where
and how the ductwork will be installed.
• A straight or short duct run will allow the unit to perform most efficiently. Long duct runs, elbows and transitions
will reduce the performance of the unit. Each elbow is equivalent to 5 to 10 feet (1.5 m to 3 m) of straight run.
Proper size duct work should be 6 in. (15.3 cm) in diameter.
• To reach a 9 foot ceiling make sure hood is installed 30 in. (76.2 cm) from cooking surface.
• If ductwork is already installed, ensure ductwork is free from debris and measures 6 in. (15.3 cm).
• Install a 120 V 60 Hz electrical outlet on the ceiling within the dimensions of the decorative chimney. Note: Removal of
the plug will void the warranty of the range hood.
• Note that the bottom of the bracket must be level to ensure that the island range hood hangs level.
STEP 4
Test Unit Functions
• Plug the unit in and test all of the functions before installing.
• Place the range hood on a flat, stable surface. Connect the range hood to a designated standard outlet (120-Volt, 60Hz,
AC only) and turn on the range hood. Verify all operations of the range hood by referring to Range Hood Operations.
• Turn power On in control panel.
• Check all lights and fan operations.
WARNINGS:
• Please make sure to read ALL safety instructions on pages 4 and 5.
• Use two or more people to move and install range hood.
• Failure to follow these instructions can result in serious injury.

Installation
