Ancona IGCP430 User Manual And Installation Instructions

Under cabinet range hood

Advertisement

Quick Links

Under Cabinet Range Hood
User Manual
and
Installation Instructions
IMPORTANT SAFETY INSTRUCTIONS
Carefully read the important information
regarding installation, safety and maintenance.
Keep these instructions for future reference.
MAAN1249-EN-04
2020-06-12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IGCP430 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ancona IGCP430

  • Page 1 Under Cabinet Range Hood User Manual Installation Instructions IMPORTANT SAFETY INSTRUCTIONS Carefully read the important information regarding installation, safety and maintenance. Keep these instructions for future reference. MAAN1249-EN-04 2020-06-12...
  • Page 2: Before You Begin

    Before You Begin INSTALLERS - Start Here Safety Instructions are on pages 4 to 6 and Installation Instructions are on pages 9 to 17. Please perform these steps: 1. Read the safety instructions. 2. Read all instructions in the Installation section of this manual BEFORE installing the range hood.
  • Page 3: Table Of Contents

    Table of Contents Before You Begin ..........................2 Table of Contents ..........................3 Important Safety Information ......................4 Included Parts ........................... 7 Range Hood Dimensions ........................8 Speci cations ............................ 8 Installation ............................9 Step 1 - Read the Safety Instructions .................... 9 Step 2 - Unpack Range Hood and Prepare Tools ................
  • Page 4: Important Safety Information

    Important Safety Information READ ALL INSTRUCTIONS BEFORE USE Read and follow all instructions before using the range hood to prevent the risk of re, electric shock, personal injury, or damage when using the range hood or appliances with the range hood. This guide does not cover all possible conditions that may occur.
  • Page 5 Important Safety Information WARNING: TO REDUCE RISK OF A RANGE To reduce the risk of injury to persons in the TOP GREASE FIRE: event of a gas leaks: a) Never leave surface units unattended at high settings. Boilovers cause smoking and greasy DO NOT turn on the lights or any type of appliance.
  • Page 6 Important Safety Information WARNING: TO REDUCE RISK OF A RANGE 7. Two installers are recommended because of TOP GREASE FIRE: 1. To reduce risk of re and to properly exhaust 8. This product is equipped with a thermostat air, be sure to duct air outside. Do not vent which may start blower automatically.
  • Page 7: Included Parts

    Included Parts Range Hood Vent-round Vent-rectangle Metal cover 2 Filters Rectangle bracket 9 + 1 Mounting screws (8MM) Hardware Note: For safety reasons, range hood mounting screws and anchors will not be included due to the variation of cabinetry constructions and wall material. Please consult your installation specialist regarding the optimal type of mounting screws and wall anchors to suit your home’s construction.
  • Page 8: Range Hood Dimensions

    Range Hood Dimensions 8.3 cm (3 1/4 in.) Speci cations Body Design Stainless Steel Power Rating Total Input Power 175 W (135 W + 2 × 20 W) Motor Input Power 135 W Amperage 1.3 A Speed Control Levels 3 Speeds Interference Protection Radio Frequency Interference Protected Motors...
  • Page 9: Installation

    Installation STEP 1 Read the Safety Instructions It is very important to read the safety instructions on pages 4, 5 and 6. IMPORTANT: It is the installer’s responsibility to comply with installation clearances. STEP 2 Unpack Range Hood and Prepare Tools Carefully unpack the range hood and parts.
  • Page 10: Step 5 - Venting Installation Guidelines

    Installation STEP 5 Venting Installation Guidelines The following steps are for exterior ventilation. IMPORTANT: For the most efficient and quiet operation: Vent system must terminate to the outside (roof or side wall). terminate the vent system in an attic or other vertically through the roof through 6 in.
  • Page 11 Installation electric cook tops and minimum of 30-inch (76.2 cm) IMPORTANT: for gas stove tops and no higher than 30-inch (76.2 cm) A minimum of 6 in. (15.3 cm) round or 3-1/4 × 10 in. (8.3 for electric cook tops. cm ×...
  • Page 12: Step 6 - Preparations

    Installation STEP 6 Preparations NOTE: To avoid damage to your hood, prevent debris from entering the vent opening. Determine and mark the centre line on the ceiling or wall where the range hood will be installed. Make sure there is proper clearance within the ceiling or wall for exhaust vent. secure in the ceiling or wall.
  • Page 13: Step 9 - Attaching Vent

    Installation A metal cover is included, to protect the motor. To install, loosen and remove the 4 screws, then put the metal cover on and tighten the screws. Figure #3 STEP 9 Attaching Vent There are 3 venting ways, with 2 type of damper options, one is 6 in. round (15.3 cm), another is 3 1/4 × 10 in (8.3 cm × 25.4 cm) rectangle.
  • Page 14 Installation Top venting using rectangular damper: If you require rectangular top (vertical) venting simply install the rectangular damper provided (See Figure #8, #9 and #10). Use screws 9 pieces 4 × 8MM to connect damper. Figure #8 Figure #9 Fix rectangle damper to the top by screws 9 pieces 4 ×...
  • Page 15: Step 10 - Installing The Hood

    Installation STEP 10 Installing the Hood Method 1: Attaching the unit to the wall The following drawings show the mounting dimensions of the 30 in (750 mm). Mark or drill 4 small holes on the mounting position according to the dimensions on Figure #14. Insert 4 drywall anchors into the holes, and 2 screws into the top holes Hang the range hood onto the screws.
  • Page 16: Step 11 Venting

    Installation STEP 11 Venting Depending on exterior ventilation chosen (see page 10), either exit the ducting through the ceiling or wall. seal with certi ed aluminum or foil tape so that it is airtight. Please check the building codes in your city to learn which tape product is recommended.
  • Page 17: Step 12 - Install Filters

    Installation STEP 12 Install Filters To install lters, follow these four steps (See Figure #18): Angle the lter into slots at the back of the hood. Push the button on handle of the lter. Release the handle once the lter ts into a resting position. Repeat to install all lters.
  • Page 18: Operation

    Operation Stop Medium High Light Speed Speed Speed Power Settings Press the button once and the motor starts to operate at Low speed. Press the button and the motor will reach Medium speed. Press the button the motor will reach High speed.
  • Page 19: Maintenance

    Maintenance Replacing the Light Bulbs IMPORTANT: ALWAYS SWITCH OFF THE ELECTRICITY SUPPLY AT THE MAIN PANEL BEFORE CARRYING OUT ANY OPERATION ON THE APPLIANCE. Make sure the range hood is unplugged or turn OFF Replace with Type MR16, 120 Volt, 20 Watt Max, breaker.
  • Page 20: Range Hood Assembly

    Range Hood Assembly Range Hood Assembly Number Part Number Part Vent (rectangle) Vent (rectangle) Vent (round) Vent (round) Rectangle bracket Rectangle bracket Housing Housing Motor bracket Motor bracket Slot Slot Blower assembly (include motor) Blower assembly (include motor) Wheel Wheel Metal ring Metal ring Metal cover...
  • Page 21: Assembly

    Assembly Circuit Diagram C ap ac it or AC 120V 60Hz Blower Assembly Number Part Ring Blower Propeller Motor Bracket of Motor Electrical Assembly Number Part Screws Transformer Terminal Box base Connector Capacitor — 21 —...
  • Page 22: Troubleshooting

    Troubleshooting Problem Cause Solution Light on, but motor does not The motor blocked Get rid of the blocking work The capacitor is damaged Have capacitor replaced The motor bearings are jammed Have motor replaced or damaged Light does not work, motor does Beside the mentioned above, check the following: not work Light is damaged...
  • Page 23: Use And Care Information

    Use and Care Information Operations Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. Always leave safety grills and lters in place. Without these components, operating fans could catch on to hair, ngers and loose clothing.
  • Page 24 Ancona is in association with Mr Appliance for all after sales service calls. Please contact their service provider or visit their website: Phone: 888-998-2011 Website: www.mrappliance.com MAAN1249-EN-04 © 2020 Copyright of Ancona Home. All rights reserved. This material may not be reproduced, displayed, modi ed or distributed. — 24 —...
