Installation

Installations (refer to Page 4 for parts): ( f t P
I t ll ti
1. Measure the distance between stove top and the bottom of
range hood. A distance of 27" to 30" is recommended*.
*Due to different ceiling height configurations, recom-
mended height may not be applicable.
1. You have two ways (A or B) to mount this range hood:
A–1. Proceed if you would like to mount this range hood
A–2. Using references in
ter the hood beneath the cabinet and flush with the front of the cabinet.
A–3. Draw electrical wires through cabinet access opening and center the hood beneath the cabinet.
A–4. From inside of the hood, place screws into the exact center of each knockout hole and secure to cabinet
bottom. Finish tightening all screws until secure. Be careful when using electrical screwdriver, damage
to the range hood may occur. Skip Part B below and proceed to Step 2.
CAUTION: Make certain the range hood is secure before releasing!
B–1. Proceed if you would like to mount this range hood using the provided hood-mounting bracket.
B–2. Using references in
the leveling point of the hood. Position two mounting screws on the wall, leaving 1/8" space away from
the wall. Mounting the hood on wall studs or lumbers is highly recommended.
B–3. Puncture the knockout wire access hole at the back of the hood and draw the electrical wires through
as shown in Figure 4.
B–4. Attach each hood-mounting bracket to the back of the hood with 4 flat head screws as shown in Figure 5.
B–5. Align hood-mounting bracket to the screws on the wall and hook hood into place as shown in Figure 6.
Tighten screws to secure hood to the wall.
CAUTION: Make certain the range hood is secure before releasing!
2. For safety purpose, pre-drilled mounting holes are provided through the back of the hood. For a more secure
installation, use as many mounting holes as needed to secure from the inside of hood.
3. Use 8" round steel pipe (follow building codes in your area) to connect the exhaust on the hood to the duct-
work above. Use silver tape or duct tape to make all joints secure and air tight. Refer to Figure 7.
SAFETY WARNING: Risk of electrical shock. this range hood must be properly grounded. Make sure this
is done by qualified electrician in accordance with all applicable national and local electrical codes. Before
connecting wires, switch power off at service panel and lock service panel to prevent power from being
4. Connect the range hood to a designated standard outlet (120-Volt, 60Hz, AC only) or cut off the plug and con-
nect three wires (black, white and green) to house wires and cap with wire connectors. Connect according to
colors (i.e. black to black, white to white, and green to green) as shown in Figure 8.
Figure 4
4 f
Height & Clearance on Page 5 and Measurements and Diagrams on Page 16, cen-
Height & Clearance on Page 5 and Measurements and Diagrams on Page 17, mark
switched on accidentally.
Figure 5
without using the hood-mounting bracket.
Figure 6
Page 10
