Step 4 - Connect Power - Extron electronics HC 402 EU Setup Manual

ATTENTION:
• If the HCT will be installed into fine furniture, it is best to hire a licenced, bonded craftsperson to cut the access hole and
perform the physical installation so the surface will not be damaged.
• S'il est prévu d'installer le HCT dans du beau mobilier, il est préférable de faire appel à un artisan autorisé et qualifié pour
couper le trou d'accès et réaliser l'installation de telle façon que la surface ne soit pas endommagée.
• Follow all national and local building and electrical codes that apply to the installation site.
• Respectez tous les codes électriques et du bâtiment, nationaux et locaux, qui s'appliquent au site de l'installation.
Americans with Disabilities Act (ADA) compliance
When planning where to install the HC system, you may need to consider factors affecting accessibility of the units such as height
from the floor, distance from obstructions, and how far a user must reach to press the buttons or insert a cable. For guidelines,
see sections 307 ("Protruding Objects") and 308 ("Reach Ranges") of the 2010 ADA Standards for Accessible Design available at
http://www.ada.gov/regs2010/2010ADAStandards/2010ADAStandards.pdf.
Site preparation
The HCT 101 EU fits a standard one-gang European (EU) wall (junction) box or external wall box with mounting holes that are
60 mm on center, or Extron Flex55 enclosures.
The HCT 101 MK fits a standard one-gang MK-type junction box or external wall box.
• The end user or installer must furnish the wall (junction) box. It is not included with the unit.
• Read any installation instructions and safety and regulatory guidelines that come with the wall box before installation.
• Protect the mounting surface to prevent damage.
To prepare the site:
For installation into a wall or furniture: Measure, mark, and carefully cut a hole in the mounting surface.
1.
For all types of installations: Run cables to the junction box.
Secure the cables with a clamp for strain relief and so they do not slip back down into the wall or furniture.
2.
Secure the box to the raceway, stud, wall, or furniture.
3.
For wall mount installations, attach the metal mounting bracket to the junction box or external wall box.
4.
For raceway installations, attach the metal mounting bracket to the junction box or external wall box and raceway.
Hold the mounting plate and feed the cables through the mounting plate.
a.
Place the mounting bracket against the box, aligning the holes in the plate with the corresponding threaded holes on the
e.
edges of the box.
Insert the provided screws into those holes, hold the metal mounting bracket to ensure it is aligned straight (visually
f.
level), and tighten the screws to secure the plate to the mounting surface.
Step 3 — Connect AV, Interconnection, and Control Cables
Ground the HCT 101 EU or HCT 101 MK transmitter (see
1.
Connect AV sources to the input connectors (see
2.
Use a shielded twisted pair cable to connect the transmitter to the receiver via the Output and Input RJ-45 connectors (see
3.
Transmitter-Receiver Interconnection
Connect AV output devices (display, projector, or other device, and an amplifier or powered speakers) to the output
4.
connectors (see AV Outputs
Cable the control ports on the receiver as desired for controlling AV devices and for communicating with the system via LAN
5.
(see Control on page 11).
Step 4 — Connect Power
Connect the power supply or power supplies to the HC 400 Series system (see
power on all the devices.
NOTE:
The power supplies can be set on a tabletop, or mounted to a rack or furniture. Follow the mounting directions
included with each power supply or see the power supply installation guides available on the
page on the Extron website.
Grounding
AV Inputs
on page 10).
on page 11).
on page 12).
on page 10).
Power on page 13), connect power cords, and
PS Series Power Supplies
5
