- Page 1 INSTRUCTION MANUAL AIR 12 www.aivituvin.com...
- Page 3 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 4: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 30MIN. ASSEMBLY HARDWARE M3.5x40m SCREW M3.5x45mm SCREW 8PCS+1spare 2PCS+1spare M3.0x16mm SCREW M3.0x25mm SCREW 10PCS+1spare 10PCS+1spare Roof hinge Foot pad 4PCS... - Page 5 PARTS Left panel Front panel Back panel Bottom floor Right panel Bottom floor Roof Eaves Curtain...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Attach the curtain part H to front panel part A by 2xP3 screws. Attach the Eaves part G above the door by 2xP1 screws. - Page 7 PRODUCT ASSEMBLY Attach the back panel part B to side panel part C & D by 4xP2 screws. Attach the front panel part A to the hutch by 4xP2 screws.
- Page 8 PRODUCT ASSEMBLY Put the bottom floor part E & F inside the hutch as show on the pictures. Attach the roof panel part I to the hutch by 6xP4 screws.
- Page 9 PRODUCT ASSEMBLY Screw the roof hinge P5 to connect the roof and side panel by 4xP4 each side.
- Page 10 PRODUCT ASSEMBLY Attach the foot pad 4XP6 to each legs by 8xP3 screws.
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
