INSTRUCTION
MANUAL
XZ7001 XZ7003
WARNING
Maunfacturer and seller expressly disclaim any and all liability for personal injury,property
damage or loss,whether direct,indirect,or incidental,resulting from the incorrect
attachment,improper use,inadequate miantenance,or neglect of this product.
www.aivituvin.com
Advertisement
Table of Contents
Related Manuals for aivituvin XZ7001
Summary of Contents for aivituvin XZ7001
- Page 1 INSTRUCTION MANUAL XZ7001 XZ7003 WARNING Maunfacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product. www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
- Page 3 TOOLS REQUIRED PARTS Front panel of hutch Back panel of hutch Right panel of hutch PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x50mm SCREW M3.5x40mm SCREW 4PCS+1 spare 18PCS+1 spare Front panel of pen Back panel of pen Left side panel of pen M3.5x25mm SCREW M3.0x16mm SCREW...
- Page 4 PARTS PRODUCT ASSEMBLY Attach Part A, Part B and Part C by 6pcs of P2 screws. Pen roof Huntch roof Ramp Casters without brake Brake Casters 2 PCS 2 PCS Attach Part G to Part A and Part B by 4pcs of P2 screws.
- Page 5 PRODUCT ASSEMBLY PRODUCT ASSEMBLY Attach the pen Part D,Part E,Part F by 4 pcs of P2 screws. Repeat on the other side. Attach the pen to hutch by 2pcs of P1 screws. Slide in two trays.
- Page 6 PRODUCT ASSEMBLY PRODUCT ASSEMBLY Screw two brake casters Part N to the back of hutch legs by P3x8. Put in rabbit chewing toy. Screw two casters without brake Part M to the front of hutch legs by P3x8. Put ramp Part L on the divider panel.
- Page 7 PRODUCT ASSEMBLY PRODUCT ASSEMBLY ① Attach the pen roof Part J by 4pcs of P2 screws. Screw the roof hinge to the back by 3pcs of P4 screws on each side. ② Screw the roof hinge P6,one side to the roof by P4x2,the other side to the right panel by P4x2.
- Page 8 Once the items are received, opened, and deemed to be faulty or other problems. Pls contact us at service@aivituvin.com for the solution. We will feedback to you within 24 hours. If you are happy with the shopping ,welcome to share photos and thoughts with others .
