- Page 1 INSTRUCTION MANUAL AIR 58 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x40mm SCREW M3.5x50mm SCREW 22PCS+1 spare 4PCS+1 spare M3.5x25mm SCREW M3.0x16mm SCREW 28PCS+1spare 8PCS+1spare M3.0x10mm SCREW 2PCS 2PCS+1 spare Bowl... - Page 4 PARTS Front panel of small house Back panel of small house Roof of small house Side panel of small house 2PCS 2PCS 2PCS 4PCS Lower panel-front Right panel-down Lower panel-back Left panel-down Casters Casters with brake Bottom floor Tray 2PCS 2PCS...
- Page 5 PARTS Left panel-upper Right panel-upper Short ramp Wooden board 1PCS Upper panel- back Upper panel-front Upper floor Small floor Long ramp Roof...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Attach the 2 small houses, screw panel Part A&C to side panel Part ① B by 8XP3. ② Attach the roof panel Part D by 4XP3 screws. Attach the side panel Part G&H to Part E&F by 8XP2 screws each side. - Page 7 PRODUCT ASSEMBLY Attach the caster Part I by 8XP3 screws. Attach the caster Part J by 8XP3 screws.
- Page 8 PRODUCT ASSEMBLY Slide in the bottom floor Part K. ① Slide in the tray Part L. Hang the ramp Part N on Part M , then put it in the cage. ② ...
- Page 9 PRODUCT ASSEMBLY Connect Part O, P, Q, R by 10XP2 and 4XP1 screws.
- Page 10 PRODUCT ASSEMBLY ① Put in the floor Part S. If you want two floors separated, then you cover the small floor Part T. ② If you want two floors connected, pls attach the ramp Part U by 2XP5 ③ screws. Put in two small houses, chewing toy and food bowl.
- Page 11 PRODUCT ASSEMBLY Attach the roof Part V by 4XP2 screws. Attach the lock Part P6 by 8XP4 screws.
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
