- Page 1 INSTRUCTION MANUAL AIR 32 www.aivituvin.com...
- Page 3 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 4: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x40mm SCREW M4.0x50mm SCREW 22PCS+1spare 10PCS+1spare M3.5x25mm SCREW M3.5x35mm SCREW 8PCS+1spare 7PCS+1spare Spring latch M3.0x16mm SCREW 3PCS 10PCS+1spare... - Page 5 PARTS Front wire panel of coop Back panel of coop Front panel of coop Back wire panel of coop Left panel of coop Right panel of coop Front panel of pen Back panel of pen Right panel of pen...
- Page 6 PARTS Ramp Pen roofs Tray Perch Back panel of nesting Front panel of nesting 2PCS Side panel of nesting box Bottom floor Divider...
- Page 7 PARTS Coop roofs Nesting box roofs 2PCS PVC Waterproof Strip Coop Nesting box...
-
Page 8: Product Assembly
PRODUCT ASSEMBLY Attach the front and back panel of coop Part A & B, left and right panel of coop Part E & F by 8xP2 screws. Attach the front and back wire panel of coop Part C & D , front and back panel of pen Part G &... - Page 9 PRODUCT ASSEMBLY Screw the ramp Part K to the bottom half of lower panel on Part F by 4xP5 screws. Attach the right panel of pen Part I to the sides by 4xP2 screws.
- Page 10 PRODUCT ASSEMBLY ① Insert 2PCS perches Part M into the slots inside front and back panel of coop. ② Slide in tray Part L. Attach the back panel of nesting box Part N and front panel of nesting box Part O to the coop by 2xP2 screws on wood Part and 4xP1 screws on wire part.
- Page 11 PRODUCT ASSEMBLY Attach the nesting box side panel Part P to the sides by 4xP2 screws. ① Drop in the bottom floor Part Q to the nesting box. ② Insert the divider Part R into the slots of bottom floor.
- Page 12 PRODUCT ASSEMBLY Attach the nesting box roof Part S by removable hinge as show on below pictures. Attach the roof panel of pen Part J to the pen by 4xP2 screws.
- Page 13 PRODUCT ASSEMBLY Attach 2PCS coop roofs Part T to the coop by 8xP3 screws.
- Page 14 PRODUCT ASSEMBLY ① Ensure top roof panels line up with each other before screwing U by 4xP4 screws. the cap Part ② Attach the spring latch P6 to the front doors by 2xP5 screws each. (Notice the direction of latch)
- Page 15 PRODUCT ASSEMBLY Attached PVC Waterproof Strip Part V to the nesting box by 3XP4 screws. Finish...
- Page 16 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
