- Page 1 INSTRUCTION MANUAL GUT02 www.aivituvin.com...
- Page 3 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
- Page 4 TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 30MIN. ASSEMBLY HARDWARE M3.5x60mm SCREW M6.0x90mm SCREW 20PCS+ + 1 spare 4PCS spare M3.5x35mm SCREW 36PCS++ 1 spare...
- Page 5 PARTS Short panel Leg B Leg A 2 PCS 2 PCS 4 PCS Short panel with slot Long panel-Second level Long panel with slot 2 PCS 2 PCS 2 PCS Long panel-Bottom level Bottom panel H Bottom panel I 2 PCS 1 PC 2 PCS...
- Page 6 PARTS Supporting panel K Bottom panel J Base panel 2 PCS 2 PCS 12 PCS Supporting for side table Divider O Side table panel 2 PCS 1 PC 3 PCS Leg end Divider P Inner lining 1 PC 4 PCS 1 PC...
-
Page 8: Product Assembly
PRODUCT ASSEMBLY ① Slide two Part C and one Part D short panels into Part A & Part B legs Secure panels with P2X4. ② Repeat to build another set of legs. - Page 9 PRODUCT ASSEMBLY Slide a Part G, Part F,Part E orderly into the legs.Secure panels with P2X4. Repeat on the other side.
- Page 10 PRODUCT ASSEMBLY Insert two Part J and one Part H,two Part I bottom panels. Attach Part K to legs with bolt P1X2...
- Page 11 PRODUCT ASSEMBLY Repeat on the other side. Attach Part L to Part K with P3X12. LX12...
- Page 12 PRODUCT ASSEMBLY Screw P3X12 on the other side. Insert the Part R inner lining.
- Page 13 PRODUCT ASSEMBLY Stuck in divider one Part P and three Part O into the slots. ① Attach two Part M to with P2X4. The side table can be assemble on left/right side either. Both 【 ② 】 pre-drilled are included！...
- Page 14 PRODUCT ASSEMBLY Attach Part N to the Part M with P3X4. ① 【 The side table can be assemble on left/right side either. Both ② pre-dilled holes are included! 】 Attach four Part Q leg ends with P3X8.
- Page 16 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
