- Page 1 INSTRUCTION MANUAL AIR 80 AIR 81 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 30MIN. ASSEMBLY HARDWARE M6.0x30mm SCREW M6.0x55mm BOLT 4PCS 8PCS M3.5x35mm SCREW M3.0x34mm SCREW 12PCS+1spare 8PCS+1spare M3.0x14mm SCREW M3.0x18mm SCREW 6PCS+1spare 11PCS+1spare Connection strap 2PCS... - Page 4 PARTS Back metal bar-left Back metal bar-right Plastic feet 4PCS Back panel Side panel Front metal bar-left 2PCS Front metal bar-right Front panel PVC curtain...
- Page 5 PARTS Roof supporter Roof Bottom panel 2PCS 2PCS 2PCS Right panel of porch Left panel of porch Roof cap Left metal bar of porch Right metal bar of porch Bottom panel of porch...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Attach the plastic feet Part C to the metal bars Part A & B with the buckle. Attach the panel Part E & Part D with the metal bars Part A & B by 4xP2 screws. - Page 7 PRODUCT ASSEMBLY Attach the plastic feet Part C to the metal bars Part F & G with the buckle. Screw the curtain Part I to the INSIDE of Part H by 3xP5 screws.
- Page 8 PRODUCT ASSEMBLY Attach the Part H to the house with the metal bars Part F & G by 4XP2 screws. Put down the bottom floor Part J.
- Page 9 PRODUCT ASSEMBLY Screw Part L INSIDE of Part K by 6XP4 screws. (There are pre-drilled holes on Part K). Attach Part K to the house by 8xP3 screws.
- Page 10 PRODUCT ASSEMBLY Attach Part M to the roof by 4xP5 screws. Attach the panel Part N & Part O with the metal bars Part P & Q by 2xP5 screws on each side.
- Page 11 PRODUCT ASSEMBLY Attach Part R by 4xP1 bolts. Attach the porch to the house using the P7 connection strap by 3xP6 screws on each side. Finish...
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
