Hex File Burning Instructions for Experienced ZDS II Users
The following instructions describe the process for burning a hex file to a ZGP323 OTP
chip.
1. Connect the Z8 GP ZGP323 Programming System to your development PC as
described in "Installing the USB Interface Driver and Cable" on page 3.
2. Install the appropriate package converter into the ZIF socket on the Programming Sys-
tem.
3. Install the OTP chip you wish to burn into the package converter installed in the Pro-
gramming System's ZIF socket. Match pin 1 of the chip with pin 1 of the package con-
verter's ZIF socket.
4. Stop any current debugging process by selecting
5. In ZDS II, open any project, such as
c:\Program Files\ZDSII_Z8GP_<version>
\samples\ZGP323_ledBlink\ledblink_c\src\ledblink_c.pro
6. In the Debugger tab of the Project Settings window, select
down menu.
7. Select
UM019101-0305
Downloaded from Elcodis.com electronic components distributor
Tools > OTP Programming
Hex File Burning Instructions for Experienced ZDS II Users
Z8 GP™ ZGP323 Programming System
Build > Debug > Stop Debugging
ledblink_c.pro
to open the OTP window (Figure 4).
User Manual
located in
.
from the drop-
USB driver
