Programming System Components
The Z8 GP ZGP323 Programming System circuit board contains three LED indicators:
• Yellow LED D1: Flashes as data is received over the USB connection from the PC.
• Red LED D3: Illuminates during OTP programming or reading.
• Green LED D5: Illuminates when 5VDC is applied to the programmer.
The following components are for factory use only:
• Jumper JP1, which must be IN.
• Jumpers JP2 through JP7.
• Connector P1 (ZDI).
• Header J1 (ISP).
• Test points TP1 and TP2.
The remaining components are not user-serviceable.
Using ZDS II to Burn a Hex File into a ZGP323 OTP Chip
After installing the ZDS II software and setting up the hardware, use the following proce-
dure to open the sample project named
gram, and burn that hex file into the supplied ZGP323 28-CDIP chip via the OTP
programming module.
Note:
The sample project
in:
c:\Program Files\ZiLOG\ZDSII_<product>_<version>
1. Start ZDS II for the Z8 GP ZGP323 programming system.
2. Open the sample project file:
c:\Program Files\ZDSII_Z8GP_<version>
\samples\ZGP323_ledBlink\ledblink_c\src\ledblink_c.pro
3. In ZDSII, open the
UM019101-0305
Downloaded from Elcodis.com electronic components distributor
If you are familiar with using ZDS II to create hex files and have previously
used the Z8 GP ZGP323 programming system, refer to "Hex File Burning
Instructions for Experienced ZDS II Users" on page 9
ledblink_c.pro
\samples\<processor type>_<demo name>
\<demo name>_<language>\src
menu and select
Build
Z8 GP™ ZGP323 Programming System
ledblink_c.pro
is included in the ZDS II sample directory, located
File –> Open Project –>
Set Active Configuration
User Manual
, build a hex file from the pro-
.
.
