2. Select the plug configuration specific to the power requirements of your locale and
insert it into the slot that remains after removing the slide-out plate.
3. Slide the new plug configuration into the slot until it snaps into place.
4. Plug the power supply into an electrical outlet.
Installing the USB Interface Driver and Cable
The Z8 GP ZGP323 Programming System features a USB interface. Follow the steps in
this section to install the Z8 GP ZGP323 Programming System with USB Interface and
configure the Z8 Programmer. Connect the hardware as shown in Figure 2.
When you first connect the Programming System to your computer, you need to help Win-
dows load the appropriate driver from the ZDSII installation directory or CD-ROM. You
can download ZDSII software from www.ZiLOG.com. You need to help Windows locate
the driver once only. The procedure you use depends on your Windows operating system
version.

Windows XP

1. Connect the 5 VDC power supply to the Programming System and apply power.
2. Connect the Programming System to the host PC using the USB cable.
If the
ton and click
3. In the Wizard, select
Note:
UM019101-0305
Downloaded from Elcodis.com electronic components distributor
Figure 2. Hardware Setup Using the Supplied USB Cable
Found New Hardware Wizard
to continue.
Next
Install from a list or specific location (Advanced);
If the Windows Logo testing dialog appears, select
Z8 GP™ ZGP323 Programming System
window appears, check the
Installing the USB Interface Driver and Cable
User Manual
Page 3
No, not this time
then click
Next
.
Continue Anyway
but-
.
