ZiLOG Z8 GP ZGP323 User Manual page 7

20. In the
drop-down menu.
21. Click
22. Select the appropriate package converter for the OTP chip you wish to burn. For the
windowed 28-CDIP part, select the 28-PDIP package converter.
23. Install the package converter into the ZIF socket on the Programming System. Match
pin 1 of the package converter with pin 1 of the ZIF socket. Pin numbers are silk-
screened on the board.
24. Install the OTP chip you wish to burn into the package converter installed on the Pro-
gramming System's ZIF socket. Match pin 1 of the chip (indicated by a notch on the
chip) with pin 1 of the package converter's ZIF socket.
25. Stop any current debugging process by selecting
26. Select
UM019101-0305
Downloaded from Elcodis.com electronic components distributor
tab of the Project Settings window, select
Debugger
. If prompted to rebuild the project, click
OK
Tools > OTP Programming
Z8 GP™ ZGP323 Programming System
Build > Debug > Stop Debugging
to open the OTP window (Figure 3).
Using ZDS II to Burn a Hex File into a ZGP323 OTP Chip
from the
USB Driver
.
YES
User Manual
Page 7
Driver
.
