Z8 GP™ ZGP323 Programming System
User Manual
Page 2

Software Requirements

Table 1 lists the PC requirements for running ZDS II.
Recommended Configuration
• PC running MS Windows XP, SP2
• Pentium III/500 MHz processor
• 128 MB RAM
• 35 MB hard disk space
• Super VGA video adapter
• CD-ROM drive
• USB port
• Internet browser (Internet Explorer or
Netscape)
Installing the ZDSII Software
Perform the following steps to install the software tools:
1. Load the ZDSII CD into your CD-ROM drive.
2. The CD automatically launches the DemoShield application and provides a menu to in-
stall the product and documentation. Click on the
the prompts to install ZDS II.
Note:
3. The following directory is installed on the host PC, assuming all installation settings
remain at their defaults:
C:\Program Files\ZiLOG\ZDSII_<product>_<version number>.
Configuring the 5VDC Universal Power Supply
The universal power supply kit features several different plug configurations in one box
and the power supply itself in another. The power supply ships with a slide-out plate that
must be removed to insert the location-specific plug configurations.
1. Remove the slide-out plate.
Software Requirements
Downloaded from Elcodis.com electronic components distributor
Table 1. ZDS II System Requirements
Software versions illustrated in the following figures are for reference only.
You may have an updated version.
Minimum Configuration
• PC running MS Windows 98SE/WinNT 4.0–
SP6/Win2000–SP3/WinXP–SP1
• Pentium II/233 MHz processor
• 96 MB RAM
• 12 MB hard disk space (documentation not
included)
• Super VGA video adapter
• CD-ROM drive
• USB port
• Internet browser (Internet Explorer or
Netscape)
Install Application
button and follow
