Danfoss iC7 Series Installation Manual page 6

In-bottom/Out-back Cooling Kit for FA11-FA12
Installation Guide
6X S-M10-2Z1
3 (0.1)
Illustration 4: Vent Dimensions for FA11 Mounting Plate in 800 mm (32 in) Cabinet
6 | Danfoss A/S © 2022.12
7 (0.3)
699 (27.5)
Installation
23 (0.9)
0.0
100 (3.9)
2X 137 (5.3)
158 (6.2)
169 (6.7)
314 (12.3)
326 (12.8)
2X 347 (13.7)
1645 (64.7)
AN361429392581en-000201 / 136R0253
