Danfoss iC7 Series Installation Manual page 4

In-bottom/Out-back Cooling Kit for FA11-FA12
Installation Guide
1
2
3
4
5 5
6
7
Illustration 2: Overview of In-bottom/Out-back Cooling Kit
1 Duct support gasket
2 Duct support bracket
3 M5x14 screw
4 M5x18 screw
5 Bottom duct assembly
6 M5 hex nut
4 | Danfoss A/S © 2022.12
7 Base plate
8 Top cover
9 Top gasket
10 Back duct assembly
11 Opening for duct
AN361429392581en-000201 / 136R0253
Installation
8
9
10
11
