Danfoss iC7 Series Installation Manual page 2

In-bottom/Out-back Cooling Kit for FA11-FA12
Installation Guide
Table 2: Items Supplied in In-bottom/Out-back Cooling Kits
Item
Top cover
Top gasket
Duct support bracket
Duct support gasket
Telescopic bottom duct
Ribbed EPDM rubber seal
Base plate (with opening for duct)
Back duct
6-hole back gasket
8-hole back gasket
M5x18 screw
M5x14 screw
M5 hex nut
M6x12 screw
M5 clip-on nut
2 | Danfoss A/S © 2022.12
Overview
Quantity
1
1
1
1
1
1
1
1
2
2
12
8
6
6
8
AN361429392581en-000201 / 136R0253
