Evaluation Board User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 6.
Qty Reference Designator
1 C3
2 C1,C2
4 C25, C26, C27, C34
2 C24, C33
1 D1
2 VLOGIC_EXT, EXTERNAL
1 J4
8
LK1, LK2, LK3, LK4, LK5, LK6, LK8,
1 BUF-W
1 R11
1 R10
1 R4
4 R5, R6, R12, R13
2 R8, R9
2 DGND, AGND
7 3V3, A, B, VDD, VLOGIC, VOUT, W
1 U1
1 U3
1 U5
1 U7
1 U15
1 FEC refers to Farnell Electronic Component Distributors.
Description
100 nF, 0402 capacitor
0.1 µF, 0603 capacitor
0.1 µF, 0603 capacitor
10 µF, 1206 capacitor
Green LED
2-pin connector
Receptacle, 0.6 mm, 120 way
ASE Header, 2-row, 36 + 36 way, and jumper socket, black
Header, 1-row, 2-way, and jumper socket, black
12 Ω, 0603, 1% resistor
750 Ω, 0603, 1% resistor
1 kΩ, 0603, 0.01% resistor
2.7 kΩ, 1206, 1% resistor
0 Ω, 0603 resistor
Test point, PCB, black, PK100
Test point, PCB, red, PK100
AD5110
ADA4860
ADP3303
24LC64 serial EEPROM
AD8652
Rev. 0 | Page 11 of 12
Supplier 1 /Part Number
FEC 1414580
FEC 138-2224
FEC 301-9482
FEC 197-130
FEC 579-0852
FEC 151789
Digi-Key H1219-ND
FEC 148-535 and FEC 150-411
FEC 102-2247 and FEC 150-411
FEC 9330534
FEC 9331506
FEC 9330380
FEC 9337288
FEC 9331662
FEC 873-1128
FEC 873-1144
Analog Devices AD5110
Analog Devices ADA4860
Analog Devices ADP3303
FEC 9758070
Analog Devices AD8652
UG-322
