10 TECHNICAL SPECIFICATION

Pump Model
General
Features
Materials
Performance
Water Tank
Connections
Pump
Electrical
Physical
Flowtech Water Solutions Ltd reserve the right to amend the specification without notice.
Noise: The equivalent continuous A-weighted sound pressure level at a distance of 1 metre
10.11
from the pump does not exceed 70 dB(A).
flowpress
Guarantee
Approvals
System Capacity
Mounting
Pump Control System
Intelligent control interface
System fill mode
Dry run protection
Typical noise
Break Tank
Front Cover
Maximum Fill Pressure
Maximum Flow
Maximum Inlet Pressure - Tank Fill Valve
Maximum Working Pressure
Ambient Air Temperature
Relative Humidity
Min./Max Water Temperature
Usable Water Capacity
Inlet Valve and fill rate
Fluid Category
Cold water inlet
Cold water outlet (flexible hose)
Overflow
Number of pumps
Pump mode
Pump Type
Motor Type
Duty Rating (Unit)
Pump Head and Seal
Power Supply (Vac/Ph/Hz)
Power Consumption - P1
Current - Full Load
Fuse Rating
Power Cable Length
Alarm Output
Enclosure Protection
Width
Depth
Height
Weight - Including Fittings
Weight Filled
Mini Digital Pressurisation Unit
flowpress Mini 130
2 Year
CE
Up to 6,000 litres
Wall mount
✔
✔
-
✔
60 dB (A)
Polyethylene
Acrylic capped ABS
3.0 bar (300 kPa)
1 l/min
7 bar (700 kPa)
6 bar
Min 4oC / Max 40oC
95 % non-condensing
Min 4 oC / Max 23 oC
2 litres
Torbeck (side entry) 12 l/min
CAT 5 (type AB air gap with weir)
G ½ male
15 mm compression x 600 mm flexible hose
G ¾ (19 - 23 mm diameter pipe compression fitting)
1
Duty
Piston
Solenoid
Int 30 mins on/30 mins off
(S3)
PA66/POM
230 V a.c. / 1 / 50 Hz
100 Watts
0.5 Amps
5 Amps
1.5 metres (pre-wired)
Single
IPX4
293 mm
145 mm
403 mm
3.6 Kg
6.6 Kg
flowpress Mini 230
✔
✔
-
✔
60 dB (A)
2
Duty-standby
Continuous (S1)
NBR
4.2 Kg
7.2 Kg
