6.16 Function list & explanation
The functions are contained within an initial display and a settings menu.
6.17 Initial display
On start up, and during normal operation, if the Flowpress Mini has had no button inputs for 1
minute, the system pressure will be displayed (see Section 7.11).
6.18 Setting of Flowpress Mini see Fig. 19
To access the setting of the Flowpress Mini see the following procedure:
1 Press and hold button A for 5 seconds.
2 P1 will be displayed and the red Error light will slowly flash. See Fig. 20.
3 Using buttons B & C select the P function required.
4 Press button A to enter the function.
5 Using buttons B & C increment the value required up and down.
6 Press button A to confirm setting.
7 Press and hold button A until the red Error light stops flashing and the Flowpress Mini
reverts to normal operation. This operation will save the changed values.
If no button inputs are received within 1 minute the Flowpress Mini will revert to normal operation and
the red Error light will stop flashing.
Note – Pumps do not operate when in the setting menu.
The following functions can be set and modified:-
P1 System pressure (2)
see Fig. 18
P2 Differential pressure (3)
see Fig. 18
P3 Hi Alarm (1)
see Fig. 18
Sets the required system pressure. Set in 0.1 bar increments
up to the maximum set value for the SPU model. SPU 130 &
230, 3.0 bar max.
Sets the pressure the SPU will turn on at as the system
pressure falls. Relative to the set system pressure. Set in
0.05 bar increments below the System pressure (2), cannot
be set above 0.1 bar below the System pressure (2).
Sets high system pressure alarm. Set in 0.05 bar increments
above the System pressure (2). Cannot be set below System
pressure + 0.5 bar. Alarm auto resets when system pressure
is reduced below alarm level.
