Teachers Microphone (Redmike); Microphone Charging Dock; Microphone - Lightspeed Redcat User Manual

Teachers microphone (Redmike)

5. Audio input: This can be used to plug in an audio source
such as a mobile phone or laptop
6. Channel A and B selection switch: This switch allows
selection between both channels. We recommend using
channel A for this microphone
7. Charger contacts: These contacts connect directly to the
charger when placed in the correct position

Microphone

1.
Place the microphone by using the lanyard
around the neck. The top of the unit should sit
approximately just below the collar bone
2. Slowly increase the channel volume on the mic
up into the Green
3. While speaking in a normal voice the correct
volume level should be as follows:
- Your voice should be clearly heard by another
person
- If a squealing noise is heard this is indicates
feedback and the volume is too loud
Prioryfield House, 20 Canon street, Taunton, Somerset, TA1 1SW |
www.robertsaudiosolutions.co.uk |info@robertsaudiosolutions.co.uk |

Microphone Charging Dock

1. Charge Indicators: These indicators will glow
teacher microphone is placed correctly into position. This
light will glow green when the microphone is fully charged.
If the light starts blinking
not sat in correctly positioned
2. DC power port: This is to connect the mains power to the
docking station
3. Handheld microphone charging socket: The charging lead
for the handheld mic is connected here
area
Tel:079100353538 | 01823323363
Red
Red this indicates that the mic is
when the
Page 2
