Connect white female 6pin Molex connector of the 6pin to 8pin cable to the male
6pin Molex connector of the video-interface.
Connect black female 8pin Micro-Fit connector of the 6pin to 8pin cable to male 8pin
Micro-Fit connector of the GM-LAN-box.
Note: Check LEDs on video-interface after reconnecting the battery, one must be on.
Connect red-green drilled cable of 6pin of 8pin cable to the male 4pin connector of
the video-interface.
Note: The GM-LAN-box is not compatible with all vehicles. If the GM-LAN-box does not
deliver ACC to pin2 of the video-interface or blocks the vehicle GM-LAN, it is possible to
install without GM-LAN -box. In this case see also note in chapter after-market rear-view
camera if one is supposed to be connected.
