Video-inserter compatible with audi vehicles with mmi navigation plus based on mib

Advertisement

Quick Links

Audi vehicles with MMI Navigation Plus based on MIB
Bentley Fahrzeuge mit MIB mit 8" Monitor
Lamborghini Fahrzeuge mit MIB mit Monitor im Tacho
Seat Fahrzeuge mit Media System Plus - MIB High/Standard
Skoda Fahrzeuge mit MIB STD2 PQ/+NAV, Amundsen und Bolero
MIB/MIB2/MQB High/Discovery Pro und Standard/Composition Media
Video-inserter with 2 video + RGB + rear-view camera input and CAN control
Product features
 Video-inserter for factory-infotainment monitors
 2 CVBS video-inputs for after-market devices (e.g. DVD-Player, DVB-T tuner, ...)
 Rear-view camera CVBS video-input
 Automatic switching to rear-view camera input on engagement of the reverse gear
 Activatable parking guide lines for rear-view camera (vehicle specific restrictions
possible)
 RGB-input for after-market navigation
 Video-in-motion (ONLY for connected video-sources)
 Compatible with factory rear-view camera
 Video-inputs PAL/NTSC compatible
Version 20.03.2017
v.LiNK Video-inserter
VL3-MIB-4
Compatible with
Porsche Fahrzeuge mit PCM 4.0
VW Fahrzeuge mit

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VL3-MIB-4 and is the answer not in the manual?

Questions and answers

Summary of Contents for v.link VL3-MIB-4

  • Page 1 Video-inserter VL3-MIB-4 Compatible with Audi vehicles with MMI Navigation Plus based on MIB Bentley Fahrzeuge mit MIB mit 8“ Monitor Lamborghini Fahrzeuge mit MIB mit Monitor im Tacho Porsche Fahrzeuge mit PCM 4.0 Seat Fahrzeuge mit Media System Plus - MIB High/Standard...
  • Page 2: Table Of Contents

    2.4.4.3. Connection Video signal 2.5. Connecting video-interface and keypad 2.6. Picture settings and guide lines 3. Interface operation 3.1. By factory infotainment button 3.2. By keypad 4. Specifications 5. FAQ – Trouble Shooting-Interface functions 6. Technical support Version 20.03.2017 VL3-MIB-4...
  • Page 3: Prior To Installation

    Read the manual prior to installation. Technical knowledge is necessary for installation. The place of installation must be free of moisture and away from heat sources. 1.1. Delivery contents Take down the serial number of the interface and store this manual for support purposes: ____________________ Version 20.03.2017 VL3-MIB-4...
  • Page 4: Checking The Compatibility Of Vehicle And Accessories

    SW-A2X1 is available. It is controlled by the video interface. Factory rear-view camera Automatically switching-back from inserted video to factory rear-view camera is only possible while the reverse gear is engaged. To delay the switch-back an additional electronic part is required. Version 20.03.2017 VL3-MIB-4...
  • Page 5: Boxes And Connectors

    Try all 6 possible combinations of Dips 6, 7 and 8 to Monitor receive the best picture (quality and size) or see chapter adjustment “Monitor adjustment (Dip 6-8)” See the following chapters for detailed information. Version 20.03.2017 VL3-MIB-4...
  • Page 6: Rear-View Camera Setting (Dip 5)

    VW Lamando 8“ VW Golf7 5.8“ 8“ Audi A3 5.8“ 8“ Audi A4 (2016) 7“ Audi A6 7“/8“ Audi Q7 (2016) with OEM Touch-Pad 8“ Audi Q7 (USA) with OEM knob 8“ Porsche Touran, Magotan GTI Audi TT Version 20.03.2017 VL3-MIB-4...
  • Page 7: Settings Of The 8 Dip Switches (Can Function - Red)

    If the necessary stabilized power supply for the interface is not taken directly from the battery, the chosen connection has to be checked for being constantly stabile. The interface needs a permanent 12V source! 2.1. Place of installation The interface is built to be connected behind the vehicle`s head-unit. Version 20.03.2017 VL3-MIB-4...
  • Page 8: Connection Schema

    2.2. Connection schema Version 20.03.2017 VL3-MIB-4...
  • Page 9 Remove the female Quadlock connector of the vehicle harness from the rear of the head-unit and connect it to the male Quadlock connector of Quadlock harness. Connect female Quadlock connector of Quadlock harness to the male Quadlock connector of the head-unit. Version 20.03.2017 VL3-MIB-4...
  • Page 10: Connecting Of Peripheral Devices

    Connect the video RCA of the AV-source 1 to the female RCA connector Video IN1 of the 20pin connection cable. Connect the video RCA of the AV-source 2 to the female RCA connector Video 2 of the 20pin connection cable. Version 20.03.2017 VL3-MIB-4...
  • Page 11: Audio Insertion

    (Audio switch - power) of the 20pin connection cable to BATT of the external Audio switch SW-A2X1. Connect the black cable (Audio switch - ground) oft he 20pin connection cable tot he grey cable of the external Audio switch SW-A2X1. Version 20.03.2017 VL3-MIB-4...
  • Page 12: After-Market Rear-View Camera

    CAM while the reverse gear is engaged. Additionally, the +12V (max. 500mA) power supply for the rear-view camera can be taken from the green wire of the 20pin connection cable. Version 20.03.2017 VL3-MIB-4...
  • Page 13: Case 2: Can-Box Does Not Receive The Reverse Gear Signal

    Connect the reverse gear light signal/power to coil (85) and ground to coil (86) of relay. Connect the rear-view camera power wire and the green rear-view camera input cable of the 20pin connection cable both to output (87) of the relay. Connect permanent battery power to input (30) of relay. Version 20.03.2017 VL3-MIB-4...
  • Page 14: Connecting Video-Interface And Keypad

    Connect the video-RCA of the after-market rear-view camera to the female RCA port of the 20pin connection cable which is labeled as CAM. 2.5. Connecting video-interface and keypad Connect the female 4pin connector of the keypad to the male 4pin connector of the 20pin connection cable. Version 20.03.2017 VL3-MIB-4...
  • Page 15: Picture Settings And Guide Lines

    Note: If there is no communication between the CAN box and the vehicle`s CAN-bus (several vehicles aren’t compatible), the .reverse gear guide-lines can`t be shown during the vehicle’s operation, even if they once appear after having switched the system to powerless! Version 20.03.2017 VL3-MIB-4...
  • Page 16: Interface Operation

    Power 0.3A @12V Video input 0.7V - 1V Video input formats PAL/NTSC RGB-video amplitude 0.7V with 75 Ohm impedance Temperature range -40°C to +85°C Dimensions video-box 155 x 22 x 90 mm (W x H x D) Version 20.03.2017 VL3-MIB-4...
  • Page 17: Faq - Trouble Shooting-Interface Functions

    Camera is being tested under Camera input picture fluorescent light which shines Test camera under natural light outside the garage. flickers. directly into the camera. Camera input picture is Protection sticker not Remove protection sticker. bluish. removed from camera lens. Version 20.03.2017 VL3-MIB-4...
  • Page 18: Technical Support

    Please note that direct technical support is only available for products purchased directly from NavLinkz GmbH. For products bought from other sources, contact your vendor for technical support. NavLinkz GmbH distribution/tech dealer-support Eurotec-Ring 39 D-47445 Moers +49 2841 949970 Email mail@navlinkz.de 10R-03 5384 Made in China Version 20.03.2017 VL3-MIB-4...
