Despatch LCC Series Owner's Manual

Stackable oven
Hide thumbs Also See for LCC Series:
Table of Contents

Advertisement

Quick Links

LCC_LCD STACKABLE OVEN
OWNER'S MANUAL
C244
PN: 320207
REVISION: B
08/2021

Advertisement

Table of Contents
loading

Related Manuals for Despatch LCC Series

Summary of Contents for Despatch LCC Series

  • Page 1 C244 LCC_LCD STACKABLE OVEN PN: 320207 OWNER’S MANUAL REVISION: B 08/2021...

  • Page 2: Revision Record

    - Updated front and sign-off pages. 2 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.
  • Page 3 DESCRIPTION: Corrected typo on first page ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 3 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 4: Table Of Contents

    4.4. Optional Beacon Light ..................... 30 4 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.
  • Page 5 7.11. Check Safety Controls .................... 71 7.12. Recalibrating Controllers ..................71 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 5 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.
  • Page 6 9.4. Electrical Schematics ....................82 6 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 7: List Of Figures

    TABLE 12. ERROR MESSAGES, POSSIBLE CAUSES, AND REMEDIAL STEPS..............81 TABLE 13. RELAY ASSIGNMENTS ..........................81 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 7 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.
  • Page 8 STAY AWAY. 8 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.
  • Page 9 FOR THE PARTICULAR HI-LIMIT INSTRUMENT FURNISHED WITH THIS EQUIPMENT. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 9 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 10: About This Manual

    10 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 11: Manufacturer & Service

    Failure to heed warnings in this instruction manual and on the oven could result in personal injury, property damage or death ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 11 of 82 countries.

  • Page 12: Conventions

    12 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 13: Specifications

    HEPA filter or filter simulator, operates at 350°C, and uses nitrogen. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 13 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 14: Dimensions

    Clear opening width is reduced by 1.5 inches (3.8cm) due to ¾ inch (1.9cm) shelf supports on each side. 14 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 15: Power

    (Figure 1). The LCC/LCD Oven is designed for 240 volts (see oven nameplate) will operate satisfactorily on a minimum of 208 Volts but will result in 25% reduced heater output. If your power characteristic is lower, contact Despatch Industries.

  • Page 16: Figure 1. Electrical Specification Label

    Figure 1. Electrical Specification Label. 16 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 17: Temperature

    Class 100 HEPA filtration will limit ramp rates. Requires water cooling be activated for minimum temp rating and operation below 85°C. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 17 of 82 countries.

  • Page 18: Figure 2. Example Design Information And Specification Label

    Specification Label. 18 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's...

  • Page 19: Capability

    Shut off electricity. Shut off fuel. Call the fire department. Stay away. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 19 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 20: Safety

    20 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's...

  • Page 21: Door And Panel

    Failure to lock out the power supply can result in death or injury. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 21 of 82 countries.

  • Page 22: Electrical Power

    22 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 23: Equipment Lockout Requirements

    DISCONNECT SWITCH shuts off all electrical power to the oven. Figure 3. Disconnect Switch. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 23 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 24: Theory Of Operation

    Trademark of SABIC Innovative Plastics. 24 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.
  • Page 25 Nitrogen atmosphere models are noted with an N suffix. Model numbers beginning with “LL*1-*” do not use a HEPA filter. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 25 of 82 countries.

  • Page 26: Standard Control System: The Protocol 3 Tm

    26 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 27: Hepa Filters

    • HEPA: High Efficiency Particulate Air ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 27 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 28: Filter Packaging, Shipping And Handling

    28 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 29: Hepa Filter: Magnehelic Pressure Gauge

    If the pressure recorded in Columns D or E decrease over time, inspect the oven seals. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 29 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 30: Optional Beacon Light

    30 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 31: Assembly & Setup

    • Check the door and latch for smooth operation. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 31 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 32: Reporting Damage & Missing Parts

    1-800-737-8110 or 1-952-469-5424 or dspsupport@itweae.com. 32 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 33: Setup The Oven

    • Plumb and level the oven to assure proper heat distribution and operation of all mechanical components. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 33 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.
  • Page 34 Material Required for stacking ovens: 34 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 35: Figure 10. Lcc/Lcd Oven Stacking Instruction Drawing

    LCC_LCD1-16/51 Oven Owner’s Manual C244, 320207, REV B ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 35 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 36: Oven Utility Connections

    36 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's...

  • Page 37: Figure 11. Lcc/Lcd Oven Utility Connections

    3. Check for leaks by slowly opening the valve on the flowmeter and allowing any air to bleed out. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 37 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.
  • Page 38 OFF, that is, fully clockwise. 38 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.
  • Page 39 Steam can burn skin. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 39 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 40: Exhaust Connections

    (160°F). 40 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's...

  • Page 41: Wiring & Power Connections

    All wiring to be completed by properly trained and licensed personnel. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 41 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 42: Figure 13. Open The Front Panel For Access

    Figure 13. Open the front panel for access. 42 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 43: Hepa Filter Handling, Installation And Burn-Off

    • Standard HEPA filter ramp rate: 1.25°C (2.25°F)/minute • High-Temperature HEPA filter ramp rate: 5°C (9°F)/minute ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 43 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 44: Hepa Filter Handling And Inspection

    Place carton on floor. 44 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 45: Hepa Filter Installation

    5.3.2. HEPA Filter Installation 1. Pull shelves from the oven and set aside. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 45 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 46: Figure 16. Remove Inner Casing To Install Hepa Filter

    (Figure 17). 46 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 47: Figure 17. Install Hepa High-Temperature Filter. (Top Sectional View Shown.)

    6. Reinstall the inner casing assembly using the three screws removed earlier. 7. Reinstall oven shelves. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 47 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 48: Hepa Filter Burn-Off

    48 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 49: Figure 19. High-Temp Hepa Filter Burn-Off Curves

    Use enough fresh air to remove the smoke, while still being able to achieve and maintain the necessary temperature. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 49 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.
  • Page 50 50 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's...

  • Page 51: Operation

    Never load a hot oven. Wait for a hot oven to cool before loading. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 51 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 52: Load Oven

    52 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 53: Pre-Startup Checklist

    Do not process closed containers of any substance or liquid in this oven because they may explode under heat. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 53 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 54: Operating Procedure

    54 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's...

  • Page 55: Start The Lcc/Lcd Oven

    ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 55 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 56: Figure 20. Power The Lcc/Lcd Oven

    Figure 20. Power the LCC/LCD Oven. 56 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 57: Sequence Of Operation For Lcc/Lcd Ovens Equipped With Optional Beacon Light

    9. Close the oven door to complete the process cycle. The oven is ready for the next lot. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 57 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 58: Sequence Of Operation For Ovens Equipped For Lcc/Lcd Inert Atmosphere Oven

    Press Run at any time to activate the Profile Mode. 58 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 59: Figure 22. Adjust Nitrogen Needle Valve (In Compartment Beneath Oven)

    (Figure 23). a. Set water cooling flow meter to 2 GPM (11 LPM) and adjust if necessary. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 59 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 60: Manual Unlock And Main Disconnect

    60 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 61: Latch Opening For The Lcc/Lcd 1-51

    2. Lift handle while holding DOOR RELEASE (Figure 25). Figure 25. Pull handle out away from door. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 61 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 62: To Close The Lcc/Lcd1-51 Oven Door

    62 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's...

  • Page 63: Working With Controls And Instruments

    ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 63 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 64: Mrc5000 Setup (Optional)

    500°F 64 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 65: Maintenance

    Contact ITW EAE - Despatch for options available to help prevent such failures. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 65 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 66: Checklist

    66 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 67: Maintenance Schedule

    (Refer to Section 7.8.) ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 67 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.
  • Page 68 Inspect HEPA filter (if equipped) condition. 68 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 69: Hepa Filter Pressure Reading Worksheet

    ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 69 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 70: Door Hinges And Latches

    70 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's...

  • Page 71: Lubrication

    2. The oven should heat and trip the High-Limit controller as it reaches the high limit setpoint. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 71 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 72: Routine Hepa Filter Inspection

    72 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 73: Cleaning The Lcc2-14 Series Oven

    ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 73 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 74: Control Cabinet Components And Cooling Fan

    Verify integrity of grounding system. 74 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 75: Clean-Up After Servicing

    7.16.2. Replacing Heater Unit Follow these guidelines to repair the oven heater unit if necessary. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 75 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 76: Replacing Hepa Filter

    76 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's...

  • Page 77: Figure 28. Hepa Filter Replacement

    To replace the filter, follow procedure detailed in Section 5.3.2. Figure 28. HEPA Filter Replacement. ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 77 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 78: Troubleshooting

    78 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's...
  • Page 79 Unbalanced fan wheel Replace and rebalance fan wheel ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 79 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 80: Heater Circuit Troubleshooting

    ON for the oven to heat up. 80 of 82 ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 81: Figure 29. Protocol 3 Heater On Indicator Light

    Position #5 End of Cycle Alarm ©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other 81 of 82 countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means without the written permission from ITW EAE - Despatch, unless for purchaser's personal use.

  • Page 82: Appendices

    9.2. Part Lists Replacement part drawings, latest revision, may be found online at https://www.despatch.com/manuals.html  Find many parts for Despatch ovens online at: http://www.despatch.com/parts.aspx. 9.3. Mechanical Drawings Mechanical outline drawings, latest revision, were shipped with the oven. Please refer to this information. Contact dspsupport@itweae.com...
