LAC/LFC Series Oven Owner's Manual
Version 1.12
LAC/LFC SERIES OVEN WITH
PROTOCOL 3™ CONTROLLER
OWNER'S MANUAL
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
Copyright © 2018 by Despatch Industries.
P
REFACE
C-266
PN 337069
VERSION 1.12
05/2018
1
