Snapmaker Dual Extrusion 3D Printing Module Quick Start Manual page 9

02
/03
Connect the Dual Extrusion Module with the controller.
Make sure the connector is in the right direction.
16
Toolhead Cable ×1
03
/03
Extend the Filament Holder Tube on the basis of the
original Filament Holder.
There is no need to detach the original Filament Holder Sheet
already installed on the machine.
Machine Assembly
Original Thumb Screw
×1
Filament Holder Tube ×1
Double End Studs ×1
Original Filament Holder Tube ×1
Original Filament Holder Sheet
×1
17
