Snapmaker Dual Extrusion 3D Printing Module Quick Start Manual page 5

1.4 Safety Labels
Labels Warning
Avoid contact with hot surfaces.
Take care to avoid crushing hands.
[1]
1.5 Specifications
Dual Extrusion Module
Product Model TH-F-DUAL-AS
Dimensions 108 mm × 70 mm × 133 mm
Weight 1 kg
Frame Material Aluminum Alloy
Input Voltage 24 V DC
Operating Temperature 15-30°C
8
Location
On the Dual
Extrusion Module
On the Dual
Extrusion Module
A150:
Dual Nozzle: 135 mm × 140 mm × 110 mm
Left Nozzle: 145 mm × 145 mm × 110 mm
Right Nozzle: 135 mm × 140 mm × 110 mm
A250:
Work Area [2]
Dual Nozzle: 220 mm × 235 mm × 205 mm
Left Nozzle / Right Nozzle: 220 mm × 235 mm × 205 mm
A350:
Dual Nozzle: 310 mm × 325 mm × 290 mm
Left Nozzle / Right Nozzle: 310 mm × 330 mm × 290 mm
Snapmaker 2.0 A150, Snapmaker 2.0 A150DET, Snapmaker
2.0 A150 Bundle, Snapmaker 2.0 A250, Snapmaker 2.0 A350,
Snapmaker 2.0 A250T, Snapmaker 2.0 A350T, Snapmaker 2.0
Compatible
A250ENT, Snapmaker 2.0 A350ENT, Snapmaker 2.0 A250DET,
Machine Models
Snapmaker 2.0 A350DET, Snapmaker 2.0 F250, Snapmaker 2.0
F350, Snapmaker 2.0 F250DE, Snapmaker 2.0 F350DE
PLA, Breakaway PLA, ABS, ASA, PETG, PVA, TPU95-HF, TPU95,
Supported
TPU90, TPU-foam, HIPS, CoPA, PA6-CF, PA6-GF, PA12-CF
[3]
Materials
Note:
[1] The specifications listed might be slightly changed in any meaningful way when
Snapmaker refines the product.
[2] Due to the installation errors generated by different users on human sensory
identification, the above work area may vary from machine to machine and is for
reference only.
[3] The hardened steel nozzle should be used when printing with CoPA, PA12-CF,
PA6-CF and PA6-GF.
Before You Start
9
