Snapmaker Dual Extrusion 3D Printing Module Quick Start Manual page 32

4.3 Clean the Extruder Gears
Why
Strong friction will be generated between the extruder gears and the filament
during printing, due to which lots of small shavings will be ground away from
the filament. If not cleaned regularly, the teeth of the extruder gears may be
flattened by the accumulated shards and particles, which will inhibit the gears
from gripping and pushing the filament through the hot end and finally affect
the printing results.
When
At least once every two weeks.
How
1. Prepare the cleaning tool: a banister brush (not provided);
2. Unload the filament from the module;
3. Power off the machine, open the front cover of the module, and press the
extruder buckle downwards to expand the dual-gear extruder;
62
4. Clean the filament shavings from the extruder gears with the banister brush.
4.4 Store the Filament
Most 3D printing filaments (especially PA, PVA, and PETG) absorb moisture
from the air, while printing with wetted filament is likely to clog the nozzles or
affect the printing quality. Therefore, the filament should be used up within one
month once unpacked.
If a spool of filament will be left unused for a long time, take the following steps
to store it properly:
1. Unload the filament from the module;
2. Store the filament in a vacuum-sealed bag filled with desiccant;
3. Mark the unpacking date on the bag.
Maintenance
63
