2.2 Scenario 2: Enclosure Installed on the Machine
If you already have the Enclosure installed on your machine, move the toolhead
and platform to proper places as illustrated above that are convenient for
detaching, demonstrated in 3.2 Change Machine Functions
Guide of the Enclosure.
Turn off the machine. Refer to Chapter 2.1 to install the Dual Extrusion Module,
and then follow Steps 01-06 to install the Filament Holder and the Filament
Tube Holder.
22
in the Quick Start
2.2.1 A150/A250/A250T/F250/A350/A350T/F350
This guide takes the Enclosure of Snapmaker A350/A350T/F350
as a demonstration to describe how to install the Filament Holder
and the Filament Tube Holder. All steps demonstrated apply to the
Enclosure of Snapmaker A150, A250/A250T/F250.
01
/06
Detach the original Filament Holder from the Enclosure,
and then install the new Filament Holder as illustrated.
Filament Holder
Original Filament
Tube
×1
Holder Tube ×1
Double End Studs ×1
New Filament
Holder Sheet
Machine Assembly
Thumb Screw ×1
×1
