PowerBOX 4

Operating Determinations

This device is not designed for permanent operation. Consistent operation breaks will ensure that the
•
device will serve you for a long time without defects.
The maximum ambient temperature t
•
The relative humidity must not exceed 50 % with an ambient temperature of 35° C.
•
If this device is operated in any other way, than the one described in this manual, the product may
•
suffer damages and the warranty becomes void.
Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
•
You endanger your own safety and the safety of others!
Improper installation can cause serious damage to people and property!
The PowerBOX 4 can be placed on a flat stage floor or attached to any kind of truss, with the 90659 –
PowerBOX clamp or the D9575B – Snap Fastener 22.

Connection with the mains

Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International
L
N
YELLOW/GREEN
Make sure that the device is always connected properly to the earth!
Improper installation can cause serious damage to people and property!
Ordercode: 90661
= 35°C must never be exceeded.
a
EU Cable UK Cable
BROWN
BLUE
US Cable
RED YELLOW/COPPER
BLACK SILVER
GREEN GREEN
4
Pin
PHASE
NEUTRAL
PROTECTIVE GROUND
