MANUAL
ENGLISH
Parcan 56 Short
V1
Ordercode: 30319/30320
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Parcan 56 Short V1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SHOWTEC Parcan 56 Short V1

  • Page 1 MANUAL ENGLISH Parcan 56 Short Ordercode: 30319/30320 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
  • Page 2: Table Of Contents

    Parcan 56 Short Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Connection with the mains ............................5 Return Procedure ................................6 Claims ....................................6 Description of the device ..............................7 Optional accessories ..............................7 Overview ..................................
  • Page 3: Warning

    Your shipment includes: ● Showtec Parcan 56 Short with 0,7m Schuko power cable ● 1x Filter frame ● User manual...
  • Page 4  If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
  • Page 5: Operating Determinations

    Parcan 56 Short Operating Determinations ● This device is not designed for permanent operation. Regular operation breaks will ensure that the device will serve you for a long time without defects. ● The minimum distance between light-output and the illuminated surface must be bigger than 0,5 meter.
  • Page 6: Connection With The Mains

    Parcan 56 Short The Parcan 56 Short can be placed on a flat stage floor or mounted to any kind of truss by a clamp. Improper installation can cause serious injuries and/or damage of property! Connection with the mains Connect the device to the mains with the power plug. Always check if the right color cable is connected to the right place.
  • Page 7: Return Procedure

    Parcan 56 Short Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture.
  • Page 8: Description Of The Device

    Parcan 56 Short Description of the device Features The Showtec Parcan 56 Short is a parcan with high output and great effects. • Lamp: PAR 56 • Lamp socket: GX16d (max 230V) • Capacity: max 500W • Input voltage: 230V, 50Hz •...
  • Page 9: Lamp Housing

    Parcan 56 Short Lamp housing Fig. 02 03) Lamp socket GX16d (230V) with terminal 04) Fixation ring Installation Remove all packing materials from the Parcan 56 Short. Check that all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. Always disconnect from electric mains power supply before cleaning or servicing.
  • Page 10: Installing The Lamp

    Parcan 56 Short Installing the Lamp The Showtec Parcan 56 Short uses the GX16d (ordercode 80103P) as manufactured by all popular manufacturers. Use only the appropriate lamp for your unit. Note that, product versions that use other lamps, may be offered in the future. Check your product specification label for information.
  • Page 11: Set Up And Operation

    Parcan 56 Short Set Up and Operation Follow the directions below, as they pertain to your preferred operation mode. Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa. Always disconnect from electric mains power supply before cleaning or servicing.
  • Page 12: Changing The Lamp

    04) If you are unable to determine the cause of the problem, do not modify the Parcan 56 Short, as this may damage the unit and the warranty will become void. 05) Return the device to your Showtec dealer. Problem...
  • Page 13: Product Specifications

    Parcan 56 Short Product Specifications Model: Showtec Parcan 56 Short Input voltage: 230V, 50Hz Capacity: max 500W Lamp socket: GX16d (max 230V) Housing: Die-cast aluminum Cooling: Convection IP rating: IP20 Power cable 0,7m with Schuko connector Filter frame: Included Dimensions:...
  • Page 14: Dimensions

    Parcan 56 Short Dimensions Ordercode: 30319/30320...
  • Page 15: Notes

    Parcan 56 Short Notes Ordercode: 30319/30320...
  • Page 16 ©2016 Showtec...
