MAX31334 Evaluation Kit
MAX31334 EV Kit Bill of Materials
REF DES
C2, C7, C8, C15
C3, C5, C9, C16-C18
C4, C11, C13, C19
C10, C12, C14, C20
C23, C24
J1, J2
J5, J8-J10, JU4
J11, JU2, JU6
JU7, JU8, JU10, JU11,
JU13, JU14, JU16
R1, R2, R5, R10
R3, R7-R9
R6
R11
SU2, SU4, SU6-SU8,
SU10, SU11, SU13-
SU16
SUPER-C
SW1
TP1-TP3, TP5
TP4, TP6, TP7
TP10, TP13
U1
U2
U5, U6
Y1, Y2
C1, C6
C21
C22
J3
J4
J6
J7
R4
U7
DS1, DS2
R12, R13
www.analog.com
MFG PART #
CL05B105KQ5NQNC
CL05B104KQ5NNN
C1005X7R1C104K050BC
C0402C103J3RAC
C1608X7R1E104K080AA
ERJ-2GEJ103
RC0402FR-0710KL
RC0402JR-070RL
CRCW06030000Z0
KW-5R5C334-R
TL2230EEF140
MAX31334EWC+
MAX31334ETB+
NLSX4373MUTAG
NX2012SA-32.768K-
EXS00A
VALUE DESCRIPTION
1UF CAP; SMT (0402)
0.1UF CAP; SMT (0402)
0.1UF CAP; SMT (0402)
0.01UF CAP; SMT (0402)
0.1UF CAP; SMT (0603)
CONNECTOR; 10PINS
CONNECTOR; 3PINS
CONNECTOR; 4PINS
CONNECTOR; 2PINS
10K RES; SMT (0402); 10K
10K RES; SMT (0402); 10K
0 RES; SMT (0402
0 RES; SMT (0603
TEST POINT
CAP; THROUGH HOLE-
0.33F RADIAL LEAD; 0.33F
SWITCH
TEST POINT
TEST POINT
TEST POINT
ADI RTC IC WLP
ADI RTC IC QTFN
NLSX4373MUTAG IC; LEVEL TRANSLATOR
CRYSTAL; SMT; 32.768KHZ;
32.768KHZ XTAL 6PF
DO NOT INSTALL
DO NOT INSTALL
DO NOT INSTALL
DO NOT INSTALL
DO NOT INSTALL
DO NOT INSTALL
DO NOT INSTALL
DO NOT INSTALL
DO NOT INSTALL
DO NOT INSTALL
DO NOT INSTALL
