Status Indicators
A.1

Front Indicators

A.1.1

Switch Indicators

Front panel LEDs are located on the right side of the chassis and display system, fan, and power supply
status. Appendix C
Figure A-1
Figure A-1: System Status Indicators
Table A-1 System Status LED States
LED State
Blinking Green
Green
Blue
Red
Quick Start Guide: 7000 Series 1 RU-Gen 2 Data Center Switches
displays the front panels of all switches covered by this guide.
shows 7124SX front panel LEDs.
Status
System powering up.
All power supplies and fans are operating normally.
The locater function is active.
Two or more fans (any combination of fan module s or PSU
fans) a re disconnected or malfunctioning. The switch will
automatically execute a "graceful shutdown" shortly.
