Assembly - Hanging the Fan (continued)
6
Install the trim ring
□
Locate the slotting inside of trim ring (D).
□
Carefully lift the trim ring (D) until the slotting in place through
the 4pcs side screws (N) which tightened in Step 5.
□
Carefully rotate trim ring (D) clockwise until it is secure.
□
Make sure that the wi anteena (L) is close to to the ceiling.
□
Remove the sticker from the antenna and stick the antenna to
the ceiling outside the ceiling fan.
D
L
Slotting
7
Install the blades
□
Remove all blade screws from the rotary plate (I) of fan-motor
assembly (B).
□
Insert the blades (K) into holes of the rotary plate (I) in place.
□
Reattach all blade screws through the blade washers and
tighten all screws to make sure the blades (K) is secure.
I
Blade screw
Blade washer
9
Please contact 1-800-986-3460 for further assistance.
Blade screw
Blade washer
K
