Home Decorators Collection OSSA CF2001-N Use And Care Manual page 7

Assembly - Hanging the Fan
1
Install the mounting plate to ceiling
□
There are 8 pre-installed screws (4 side-N; 4 bottom - M) on the
mounting plate (A).
□
Remove 2pcs opposite screws from the side and bottom of
mounting plate(A). Figure 1.
□
Attach the mounting plate (A) to the outlet box (not included)
with two screws(EE, not included) and washers(DD, not
included) supplied with the outlet box. Ensure the mounting
plate (A) is tight, level and secured. Figure 2.
NOTE: Save all screws removed to be added back in a later
step.
Side screw (N)
Bottom screw(M)
N
M
N
outlet box
A
EE
Figure 2
M N
A
M
M
Figure 1
DD
2
Hang the fan-motor Assembly
□
Carefully lift the fan-motor assembly (B) and hang the
fan-motor assembly (B) on the hook of the mounting plate
(A) by utilizing the hole edge trim of the fan-motor assembly
plate (B) and make sure it is securely suspended. Figure 3.
Elongated
shaped hole
N
7
Figure 3
HOMEDEPOT.COM/Hubspace
Please contact 1-800-986-3460 for further assistance.
B
