3. Open the two front screws of the roof sheeting to be
able to remove it.
4. Now, you can screw off the side panels top-down. Lift
the side panels and put them down safely.
830109GB/141111
Installation plan:
free space above the coverfor
Freiraum überhalb des Deckels,
für Abnahme min. 100mm
reduction of min. 100 mm
When positioning two or more heat pumps side by side, please observe a
The heat pump must be installed on a sustainable
and horizontal underground. The installation room
must be frost-protected and dry.
The heat pump must not be installed on a PUR
foam boiler platform. The heat pump must any time
be accessible for the fi tter. All parts of the heat
pump can be operated from the front.
- Subject to Technical Modifi cations -
INSTALLATION
heating suplly point/
Heizungsanschluss/
Wärmequellenanschluss
heat source supply point
heat pump
Wärmepumpe
920
operating side
Bedienseite
Schraffierte Fläche
Freiraum für Servicezwecke
operating side
Bedienseite
heating suplly point/
Heizungsanschluss/
Wärmepumpenanschluss
heat source supply point
minimum distance of 1600 mm on the operating side.
free space for service
purposes
