TECHNICAL DETAILS

SWP 390
V.813131
Heat pump type
Conformity
Installation
Protection
Power data
Heating power/COP
Power consumption
Sound
sound pressure level averaged at 1m distance to the machine (free field)
Application limits
Temperature limits heating circuit water
Temperature limits brine
Device
Dimensions, width x depth x height (without connections)
Weight including transport packing
Refrigerating agent type / charge
Heating circuit water
Minimum / nominal / maximum water flow rate
Pressure drop heat pump at nominal water flow rate
Temperature spread B0/W35
Heat source
Minimum / nominal / maximum brine flow rate
Pressure drop heat pump at nominal brine flow rate
Minimum brine / antifreeze concentration up to
Recommended brine circulation pump Grundfos type:
Total pressing of recommended pump at nominal brine flow rate
Connections
Heating circuit water
Brine
Dirt filter with 2 x 2" internal thread for brine circle, to be installed before heat pump
Power cable
Control line
Electrics
Nominal voltage / protection heat pump1)
Maximum machine current within application limits
Maximum theoretical compressor current (Imax) Klixon shift point)
Power consumption / cos at B0/W35 acc. to EN 255
Power consumption / current of brine pump at nominal flow rate
Setting range motor circuit switch
Starting current direct (locked rotor) with smooth starter (installed)
1) Observe local regulations
14
B0/W35 acc. to EN255
B0/W50 acc. to EN255
B-5/W35 acc. to EN255
B-5/W50 acc. to EN255
B../W35 and B../W50
- Subject to Technical Modifi cations -
Brine / Water
CE
Indoor
IP24
kW/- 38,2 / 4,1 (20,2 / 4,4)
kW/- 38,3 / 3,0 (20,3 / 3,1)
kW/- 34,3 / 3,7 (18,2 / 3,8)
kW/- 33,8 / 2,7 (17,9 / 2,7)
kW / kW about 9,3 and about 12,8 (4,6 and 6,5)
dB(A) 55
°C 20 to 55
°C -5 to 25
mm 920 x 800 x 1690
kg 560
- / kg R407C / 8
l/h 3300 / 3500 / 7000
bar 0,03
K 9,4
l/h 7200 / 9600 / 20000
bar 0,12
% / °C 25 / -13
CHI 8-10 (3x400V,50Hz)
bar 0,96
2 x 2" external thread
2 x 2" external thread
to be provided by customer
2
to be provided by customer
mm / m
-
V / A 400 / 40C
A 2 x 15,9
A 2 x 17
kW / A / - 9,3 / 21,8 / 0,62
kW / A 0,72 / 1,4
A 1,1 - 1,6
A / A 99 / 50
830109GB/141111
